Servo System Edge Cutting Trimming Machine For Stainless Steel Pot

1 set
MOQ
Negotiable
Price
Servo System Edge Cutting Trimming Machine For Stainless Steel Pot
Features Gallery Product Description Request A Quote
Features
Specifications
Slide Stroke (mm): 400
Return Force (kN): 2000 KN
Machine Type: Hydraulic Press Machine
System: Servo
Voltage: 380V/220V Optional
Dimension(L*W*H): 2200*2400*4200mm
Weight (T): 3.5 T
Motor Power (kw): 30 Kw
Highlight:

Servo Edge Cutting Trimming Machine

,

Stainless Steel Edge Cutting Trimming Machine

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Star Power
Certification: CU,ISO
Model Number: QXJY325-300
Payment & Shipping Terms
Packaging Details: metal frame with film
Delivery Time: 1 month
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Set/Sets per Month
Product Description

Stainless steel pot edge cutting machine beading machine



Product Description:



Wrapped by film and packed with fumigated wooden case or Steel frame pallet for container.



Quick Details:



1. Edge cutting, trimming, beading & flat beading 4 in 1


2. Capacity: 12-22s/pc, about 2400-1920pcs/10hours


3. No vibration while cutting tall hollow items or thick items


4. Save 2 worker


5. Reduce 2 machine


6. Compare to punching solution, avoid big moulds cost


7. Easy operation & changing sizes


8. Electric components
MITSUBISHI PLC, DELIXI Switch, Schneider, SMC


9. Machine solid body 10 year lifetime



Specifications:



Main Technical Parameters
Function Edge cutting, trimming, beading & flat beading
Size of workpiece ≤Φ325mm x 300mm (Dia. x H)
Thickness SS: ≤ 1.2mm, Al: ≤ 4mm
Motor power Workpiece Motor: 4kw x 1
Cutting Motor: 0.37kw x 1
Hydraulic Station: 4kw x 1
rotating speed Workpiece: 28~140RPM (Adjustable)
Cutting blades : 2160 RPM (Adjustable)
Workpiece holding Vacuum adsorption
Dimension 2150mm x 1200mm x 2000mm (L x W x H)
Weight About 1.5T



Advantages:



Servo System Edge Cutting Trimming Machine For Stainless Steel Pot 0Servo System Edge Cutting Trimming Machine For Stainless Steel Pot 1Servo System Edge Cutting Trimming Machine For Stainless Steel Pot 2
