Product Description:
Wrapped by film and packed with fumigated wooden case or Steel frame pallet for container.
Quick Details:
1. Form the forming process, adjust the striking force and combat powers base on the forging.
2. Using Switched Reluctance Drive, it has a low starting current, high starting torque, and good speed performance.
3.Save approx 50% electricity.
4.Electrical control system uses the programmable logic controller(PLC) as the master device, to realize the real-time control of the machine and man-machine interface(HMI) enables information exchange between the speed operator and the machine.
Specifications:
| Model |
Nominal pressure (KN) |
Allow the use of force (KN) |
Slide stroke (mm) |
Strokes per minute (min-1) |
Min.space for installing (mm) |
Thickness of table plate (mm) |
Table size F.B×L.R (mm) |
| EPC54-1000 | 10000 | 16000 | 500 | 18 | 600 | 180 | 1000×900 |
| EPC54-1600 | 16000 | 25000 | 550 | 16 | 750 | 200 | 1200×1100 |
| EPC54-2500 | 25000 | 40000 | 650 | 14 | 1020 | 280 | 1400×1250 |
Advantages:
