Product Description:
Wrapped by film and packed with fumigated wooden case or Steel frame pallet for container.
Quick Details:
1. Production capacity: 1s/stroke
2. Punch 1 hole, 2 holes, 3 holes, 4 holes, 6 holes, 8 holes
3. Punch exact round holes without burr, no water leakage risk on final cookware
4. Save moulds cost
5. Easy operation
Specifications:
| Main Technical Parameters | |
| Size of workpiece | Φ(140~300)mm x (40~300)mm(Dia. x H) |
| T≤ 1.2mm(SS), T≤ 4mm(AI) | |
| Hole size | Dia: Φ02-Φ8.2mm |
| Holes distance: No limited | |
| Hole center line and surface angle: -10° ~ +20° | |
| Mouth depth | 70mm |
| Motor power | Hydraulic pump motor: 3kw, 16Mpa |
| Cooling blower: 35w | |
| Servo motor: 1.5kw x1, 0.75kw x5 | |
| Punch hydraulic cylinder | Dia.: Φ50mm, travel limit: 40mm, pressure: 16Mpa |
| Dimension | 1350mm x 1237m x 1010mm (L x W x H) |
| Weight | About 1T |
