Product Description:
Wrapped by film and packed with fumigated wooden case or Steel frame pallet for container.
Quick Details:
1. Suitable for tumblers, lunch box, mixing bowl, Mosco cup etc.
2. Capacity: about 2000-2500 polishes/ 8 hours (70 x 90mm, Dia. x H)
3. Four polishing machines to match in one polishing line
4. Energy saving from less polishing time
5. Save 3 polishing workers
6. Save polishing consumable
7. Main electric components: Schneider,Elco, Delixi etc. (all brands with CE certificate)
Specifications:
| Main Technical Parameters | |
| Function | Small size utensils inside wall or bottom polish |
| Stations | ≤Φ220mmx160mm(Dia. x H) |
| Size of workpiece | ≤Φ200mmx160mm(Dia. x H) |
| Motor power | Abrasive wheel motor: 5.5kw x 1 Workpiece motor: 0.75kw x 1 X-axle servo motor: 0.55kw x 1 Y-axle servo motor: 0.55kw x 1 |
| Rotating speed |
Polishing wheel: 2160RPM Workpiece: 28-140 RPM(Adjustable) |
| Workpiece holding | Vacuum adsorption |
| Dimension | 1700 x 2100 x 2100mm (L x W x H) |
| Weight | About 3T |
