Non Stick Pan Body Production Line 260 Ton Three Beam Hydraulic Press Machine for Cookware Making

A 260 ton three beam press arranged for non stick pan production. The line draws the pan body, beads the edge and trims the rim, so pans leave with a rounded edge that holds coating at the rim and fits a handle bracket without extra machining.

• Integrated beading station rolls the pan rim before the part leaves the line
• Three beam four column frame keeps slide guidance stable at 2600 kN working force
• Pressure hold at bottom dead centre controls springback on thin gauge aluminum
• Tooling with interchangeable inserts covers 180 mm to 300 mm pan diameters
• Optional die cushion supports embossed bottoms and induction base patterns
• Hydraulic oil filtration with pressure differential indicator for maintenance planning

• Rim beading inside the same line
• 2600 kN force on a three beam frame
• Tooling covers 180-300 mm diameters
• Optional die cushion for embossed bases

Built for non stick pan, granite coated pan and ceramic coated cookware producers that need a clean rim before spraying, and for plants that press pan bodies for private label brands.

• Installation guidance, commissioning support and operator training arranged by our engineering team
• 12 month warranty on core components including motor, pump, PLC and hydraulic valves
• Spare parts stocked for fast dispatch and remote diagnostics through video inspection
