Automatic Kettle Body Deep Drawing Cookware Production Line 160 Ton Servo Driven Hydraulic Press

Brand Name:	Star Power
Model Number:	YZ28G0160T
MOQ:	1 set
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	80 Set/Sets per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE, ISO 9001

Machine Type:

Four-column Three-beam Hydraulic Drawing Press

System:

Servo Controlled Ram Profile

Blank Holder Force:

50-400 KN Adjustable

Table Size:

900*800 Mm

Working Speed:

8-14 Mm/s

Voltage:

380V/220V Optional

Dimension (L*W*H):

2000*2200*3900mm

Warranty:

1 Year

Packaging Details:

metal frame with film, tooling in separate wooden case

Highlight:

Kettle Body Drawing Line

Deep Drawing Press

Servo Kettle Forming Machine

Product Description

Automatic Kettle Body Deep Drawing Cookware Production Line 160 Ton Servo Driven Hydraulic Press

Key Specifications

Attribute	Value
Working Force	1600 kN
Stations	2 (first draw and redraw)
Max Draw Depth	180 mm
Slide Stroke (mm)	400
Motor Power (kw)	18.5 kw
Weight (T)	3.0 T

Product Overview

A two station 160 ton hydraulic deep drawing line formed around kettle shells. Blank holder pressure is set independently from punch force, so 0.4 mm to 1.2 mm stainless blanks reach 180 mm draw depth without flange wrinkling or tearing at the punch radius.

Packaging & Protection

Frame, bolster and tooling are separated for shipment, protected by anti rust oil and waterproof film, then fixed with steel brackets inside reinforced wooden cases.

Key Features

Independent blank holder pressure from 50 kN to 400 kN for wrinkle free shells
Two stations on one frame: first draw followed by reverse redraw
Servo controlled ram profile with 20 step program storage for each kettle size
Quick change punch and die set covering 1.0 L to 3.5 L kettle bodies
Water cooled hydraulic manifold holds cycle time steady through a full shift
Safety gate interlock with ram position feedback wired to the PLC

Technical Specifications

Machine Type	Four-column Three-beam Hydraulic Drawing Press
System	Servo controlled ram profile
Blank Holder Force	50-400 kN adjustable
Table Size	900*800 mm
Working Speed	8-14 mm/s
Voltage	380V/220V Optional
Dimension (LWH)	200022003900mm
Warranty	1 Year

Operational Advantages

Two station drawing on a single frame
20 programs stored for repeat kettle sizes
Changeover to a new shell under 40 minutes
±0.05 mm shell height repeatability

Application Scenarios

Built for kettle, teapot and coffee pot producers running stainless shells in the 1.0 L to 3.5 L range, including double wall bodies and whistle kettle components.

Product Images

Support & Services

Installation guidance, commissioning support and operator training arranged by our engineering team
12 month warranty on core components including motor, pump, PLC and hydraulic valves
Spare parts stocked for fast dispatch and remote diagnostics through video inspection
