Features

Specifications

Model NO.: J21S-63T

Type: Deep Throat Punching Machine

Punch Shape: Open Punch

Slider Movement: Single Action

Slider Drive Mechanism: Crank Press

Controlling Mode: Artificial

Automatic Grade: Manual

Power Source: Electric

Precision: High Precision

Condition: New

Nominal Pressur: 630kn

Slide Stroke: 100mm

Max Closing Height: 360mm

Workbench Size Front And Back*Leftandrig: 430*700mm

Transport Package: Film

Specification: 40T

Trademark: Star Power

Origin: China

HS Code: 8462490000

Production Capacity: 50units/Month

Highlight:

deep throat press machine for kitchen sinks

prebending kitchen sink press machine

kitchen sink punching machine with warranty

Basic Infomation

Certification: CE, ISO 9001

Payment & Shipping Terms

Gallery

Deep Throat Press Machine Punching for Prebending Kitchen Sink Press Machine

Product Description

Deep throat press machine Punching for Prebending kitchen sink press machine.We can provide supporting molds

Working principle and usage of presses
This press is crank as a working mechanism,crank for the steel,so the movement of the slider is mandatory,slider per minute trips and slide
motion curve is constant.
The pressure machine is suitable for cutting,punching,blanking,bending and shallow drawing,stamping,but it does not apply to printed works.
When working in all kinds of stamping presses,stamping force required (including RMA)is less than the maximum nominal power of the press, so as not to damage the parts may be calculated by reference to the relevant information.

Deep Throat Press Machine Punching for Prebending Kitchen Sink Press Machine 0

Name	Unit	Specification
Nominal Pressur	Kn	630
Slide Stroke	mm	100
Number of Stroke	Times/min	50
Max Closing Height	mm	360
Distance adjustment betweenslider bottomand worktable	mm	60
Distance fromslider centertobody	mm	500
Workbench Size front and back*leftandright	mm	430*700
Motor power	kw	4
