Product Description:
It is packed with waterproof protective film and protected by bracket or wooden box to ensure that the equipment will not be damaged by external force during transportation, which will affect the appearance and performance of the equipment.
Quick Details:
Specifications:
|
Item
|
YZ28G-200
|
|
Main cylinder force
|
1500KN
|
|
Rating working pressure of the hydraulic system
|
20Mpa
|
|
Return force
|
90KN
|
|
Cushion force
|
500KN
|
|
Cushion cylinder Max.pressure
|
20MPA
|
|
Ejection capacity
|
30KN
|
|
Max. stroke of cushion cylinder
|
300MM
|
|
Max. stroke of ejector
|
200MM
|
|
Max. stroke of slide table
|
550MM
|
|
Open height
|
Max : 950MM
|
|
Min : 400MM
|
|
|
Slide speed
|
Down : 450MM/S
|
|
Pressure : (22) 32/54 MM/S
|
|
|
Return : 480MM/S
|
|
|
Power of motor
|
30KW
|
|
Dimension of working table (RL*FB)
|
700*880 MM²
|
|
Dimension of machine(RL*FB*H)
|
1950*2100*3700MM²
|
Advantages:
