Product Description:
Wrapped by film and packed with fumigated wooden case or Steel frame pallet for container.
Quick Details:
1. Cookware set project: capacity 6000sets/month, each set makes $50 net profit, 5 years makes $18millions net profit.
2 Pressure cooker project: capacity 30000 finishes/month, each finishes makes $10 net profit, 3 years makes $10millions net profit.
3. 3plys steel cookware sets project: capacity 6000sets/month, each sets makes $80 net profit, 1 year makes $5.8millions net profit.
Industry International Limited is an engineering company.
We focus on cookware / hotelware / kitchenware / home appliance A-Z turnkey project.
We can copy the China top 10 quality factory / producing line to your country.
Specifications:
|
Item
|
YZ28G-200
|
|
Main cylinder force
|
1500KN
|
|
Rating working pressure of the hydraulic system
|
20Mpa
|
|
Return force
|
90KN
|
|
Cushion force
|
500KN
|
|
Cushion cylinder Max.pressure
|
20MPA
|
|
Ejection capacity
|
30KN
|
|
Max. stroke of cushion cylinder
|
300MM
|
|
Max. stroke of ejector
|
200MM
|
|
Max. stroke of slide table
|
550MM
|
|
Open height
|
Max : 950MM
|
|
Min : 400MM
|
|
|
Slide speed
|
Down : 450MM/S
|
|
Pressure : (22) 32/54 MM/S
|
|
|
Return : 480MM/S
|
|
|
Power of motor
|
30KW
|
|
Dimension of working table (RL*FB)
|
700*880 MM²
|
|
Dimension of machine(RL*FB*H)
|
1950*2100*3700MM²
|
Advantages:
