Hydraulic Press Cookware Production Line Machine For Metal Aluminum Kettle Making

1 set
MOQ
Negotiable
Price
Hydraulic Press Cookware Production Line Machine For Metal Aluminum Kettle Making
Features Gallery Product Description Request A Quote
Features
Specifications
Slide Stroke (mm): 1500
Return Force (kN): 30 KN
Machine Type: Four-column Two-beam Hydraulic Press
System: Servo
Voltage: 380V/220V Optional
Dimension(L*W*H): 2620*1680*6390
Weight (T): 60 T
Motor Power (kw): 75 Kw
High Light:

Cookware Production Line Hydraulic Press

,

Aluminum Kettle Cookware Production Line

,

Metal Kettle hydraulic press machine

Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Star Power
Certification: CU,ISO
Model Number: YZ28G-250
Payment & Shipping Terms
Packaging Details: metal frame with film
Delivery Time: 1 month
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Set/Sets per Month
Product Description

kettle Making Hydraulic Press Machine Metal Aluminum Cookware Kettle Production Line



Product Description:



Easy Operation: Unskilled ladies or freshman can operate the machine.
Success Rate: Productions succeed ≥ 99%.
Easy maintenance.





Quick Details:



Wrapped by film and packed with fumigated wooden case or Steel frame pallet for container.





Specifications:



Item
YZ28G-250
Main cylinder force
1500KN
Rating working pressure of the hydraulic system
20Mpa
Return force
140KN
Cushion force
1000KN
Cushion cylinder Max.pressure
20MPA
Ejection capacity
30KN
Max. stroke of cushion cylinder
300MM
Max. stroke of ejector
200MM
Max. stroke of slide table
550MM
Open height
Max: 950MM
Min : 400MM
Slide speed
Down : 450MM/S
Pressure: (22)32/54MM/S
Return: 480MM/S
Power of motor
30KW
Dimension of working table (RL*FB)
700*880 MM²
Dimension of machine(RL*FB*H)
1950*2100*3700MM²





Advantages:



Hydraulic Press Cookware Production Line Machine For Metal Aluminum Kettle Making 0Hydraulic Press Cookware Production Line Machine For Metal Aluminum Kettle Making 1Hydraulic Press Cookware Production Line Machine For Metal Aluminum Kettle Making 2Hydraulic Press Cookware Production Line Machine For Metal Aluminum Kettle Making 3
